Canon MP258 Error Code
E, 0, 2
The machine is out of paper / Paper does not feed
E, 0, 3
Paper Output Tray is closed / Paper jam
E, 0, 4 / E, 0, 5
The FINE Cartridge cannot be recognized
E, 0, 7
FINE Cartridge is not installed in the correct position
E, 0, 8
Ink absorber is almost full
E, 0, 9 (MP270 series only)
The
machine has not received a response from the digital camera. The
digital camera or digital video camcorder connected is not compatible
with this machine.
E, 1, 3
Ink level cannot be detected.
E, 1, 4
The FINE Cartridge cannot be recognized.
E, 1, 5
The FINE Cartridge cannot be recognized.
E, 1, 6
Ink has run out.
E, 1, 9 (MP270 series only)
PictBridge compliant device is connected via a USB hub.
E, 3, 0
The size of the original cannot be correctly detected or the document is too small when the Fit-to-Page copying is selected.
E, 3, 1
The machine is not connected with the computer.
E, 5, 0
Scanning the print head alignment sheet has failed.
P, 0, 2
P, *, *
E, 0, 2
Reload the paper on the Rear Tray correctly and press the Black or Color button.
Loading Paper
See[Loading Paper ]
E, 0, 3
If the Paper Output Tray is closed, open it. The machine resumes printing.
If
opening the Paper Output Tray does not resolve the problem, or if the
tray was open to begin with, the paper may be jammed. Remove the jammed
paper, reload paper properly in the printer, then press the Black or
Color button.
Paper Jams
See[Paper Jams]
E, 0, 4 / E, 0, 5
The FINE Cartridge may not be installed properly, or the Cartridge may not be compatible with this machine.
Open the Scanning Unit (Cover) and install the appropriate FINE Cartridge.
If the error is not resolved, contact the service center.
E, 0, 7
Make sure that each FINE Cartridge is installed in the correct position.
Replacing FINE Cartridges
When FINE Cartridges run out of ink, follow the procedure below to replace them.
See[Replacing FINE Cartridges]
E, 0, 8
Press the machine's Black or Color button to continue printing. Contact the service center.
E, 0, 9 (MP270 series only)
Check the device connected to the machine. Printing photos directly is possible only with a PictBridge compliant device.
A communication time out occurs if an operation takes too long or if
it takes too much time to send data. This may cancel printing. In such
cases, disconnect and reconnect the USB cable.When printing from a
PictBridge compliant device, depending on the model or brand of your
device, you may have to select a PictBridge compliant print mode on the
device before connecting it to the machine. You may also have to turn on
your device or select Play mode manually after connecting the device to
the machine. Perform necessary operations before connecting your device
referring to its instruction manual.If the error is still not resolved,
check if you can print another photograph.
E, 1, 3
Ink may have run out.
The function for detecting the remaining ink level will be disabled since the ink level cannot be correctly detected.
If you want to continue printing without this function, press the machine's Stop (Reset) button for at least 5 seconds.
Canon recommends to use new genuine Canon cartridges in order to obtain optimum qualities.
Please
be advised that Canon shall not be liable for any malfunction or
trouble caused by continuation of printing under the ink out condition.
Checking the Ink Status
You can check the ink status with the Ink lamps on the Operation Panel or with the computer screen.
See[Checking the Ink Status]
E, 1, 4
The FINE Cartridge may not be compatible with this machine.
Install the appropriate FINE Cartridge.
Replacing FINE Cartridges
When FINE Cartridges run out of ink, follow the procedure below to replace them.
See[Replacing FINE Cartridges]
E, 1, 5
The FINE Cartridge may not be installed properly.
Open the Scanning Unit (Cover) and install the FINE Cartridge properly.
Replacing FINE Cartridges
When FINE Cartridges run out of ink, follow the procedure below to replace them.
See[Replacing FINE Cartridges]
E, 1, 6
Ink has run out.
Replace the ink cartridge and close the Scanning Unit (Cover).
If
printing is in progress and you want to continue printing, press the
machine's Stop (Reset) button for at least 5 seconds with the ink
cartridge installed. Then printing can continue under the ink out
condition.
The function for detecting the remaining ink level will be disabled.
Replace
the empty ink cartridge immediately after the printing. The resulting
print quality is not satisfactory, if printing is continued under the
ink out condition.
Replacing FINE Cartridges
When FINE Cartridges run out of ink, follow the procedure below to replace them.
See[Replacing FINE Cartridges]
E, 1, 9 (MP270 series only)
If a PictBridge compliant device is connected via a USB hub, remove the hub and connect it directly to the machine.
E, 3, 0
Make sure that the original meets the requirements and is correctly loaded on the Platen Glass.
Check the position and direction of the original loaded on the Platen Glass.
E, 3, 1
Connect the machine and the computer with a USB cable.
E, 5, 0
Press the Stop/Reset button to dismiss the error, then take the actions described below.
Make sure that the print head alignment sheet is set in the correct position and orientation on the Platen Glass.
Make sure the Platen Glass and the print head alignment sheet are not dirty.
Make sure the type and size of loaded paper is suitable for
Automatic Print Head Alignment.For Automatic Print Head Alignment,
always load one sheet of A4 or letter-sized plain paper.
Make sure if Print Head nozzles are clogged.Print the nozzle check pattern to check the status of the Print Head.
->Printing the Nozzle Check Pattern
If the error is not resolved, connect the machine to the computer and align the Print Head on the printer driver.
Aligning the Print Head
If printed ruled lines are misaligned or print results are otherwise unsatisfactory, adjust the print head position.
See[Aligning the Print Head]
P, 0, 2
Cancel
printing, turn off the machine. Then clear the jammed paper or
protective material that is preventing the FINE Cartridge Holder from
moving, and turn on the machine again.
NOTE
When protective materials are not removed yet,please follow the procedures below.
1. Open the Paper Output Tray.
2. Lift the Scanning Unit (Cover) and fix it with the Scanning Unit Support.
3. Pull the orange protective tape (D) and remove the protective material (E).
4. Lift the Scanning Unit (Cover) slightly and fold the Scanning Unit Support, then gently close the Scanning Unit (Cover).
IMPORTANT
Be careful not to touch the components inside the machine. The machine may not print out properly if you touch it.
If the problem is not resolved, contact the service center.
P, *, *
"*, *" depends on the error occurred.
"P, 1, 0" is displayed:
Turn off the machine, and unplug the power cord of the machine from the power supply.Contact the service center.
"P, 0, 3" is displayed:
If
any object is placed in front of the machine, remove it.Open the Paper
Output Tray gently, then turn the power off and back on.
In other cases:
Turn
off the machine, and unplug the power cord of the machine from the
power supply.Plug the machine back in and turn the machine back on.If
the problem is not resolved, contact the service center.
